Mitutoyo 511-206 Small Hole Bore Gauge, Range 0.4-0.74", Graduation 0.0001", Probe Depth 4"
SKU:Code: 511-206
Sale
Sold out
Regular price
£391.50
Save: 25%
Sold out
Sale price
£391.50
Regular price
£522.00
Excl. VAT
The interchangeable anvils used on this gauge are made of high-grade tool steel.
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
Specification
Specification
- type Small Hole Bore Gauges
- range 0.4-0.74"
- display type Non-Digital
- graduations 0.0001"
- accuracy 0.0002"
- measuring force 2 N or less
- measuring units Imperial
- probe depth 4"
- repeatability 0.00008"
- dial indicator 2923AB-10
- anvil 9
- brand Mitutoyo
description
description
The interchangeable anvils used on this gauge are made of high-grade tool steel. Interchangeable washers 0.5 mm thick are supplied as standard accessories to enable setting the 10 - 18.5mm / 0.4 - 0.74" models in small steps. The dial indicator is fully protected by a rugged cover. An optional inside-length standard, such as a setting ring or Inside Micro Checker is required for accurately setting the gauge before measurement.
