Mitutoyo 511-211 Small Hole Bore Gauge, Range 6-10mm, Graduation 0.01mm, Probe Depth 100mm
SKU:Code: 511-211
This item is no longer available or has been discontinued.
The interchangeable anvils used on this gauge are made of high-grade tool steel.
Need more information? Ask a question or contact us.
Specification
Specification
- type Small Hole Bore Gauges
- range 6-10mm
- display type Non-Digital
- graduations 0.01mm
- accuracy 5 μm
- measuring force 2 N or less
- measuring units Metric
- probe depth 50mm
- repeatability 2 μm
- dial indicator 2046AB
- anvil 9
- brand Mitutoyo
description
description
The interchangeable anvils used on this gauge are made of high-grade tool steel. Interchangeable washers 0.5 mm thick are supplied as standard accessories to enable setting the 10 - 18.5mm / 0.4 - 0.74" models in small steps. The dial indicator is fully protected by a rugged cover. An optional inside-length standard, such as a setting ring or Inside Micro Checker is required for accurately setting the gauge before measurement.
