Mitutoyo

539-806R Range 350mm / 14" AT715 Coolant Proof Linear Scale, IP67 and Absolute System, Single Cable Length 3.5 Metres

Code: 539-806R

This item is no longer available or has been discontinued.

Only compatible with KA Counter display units. Designed to capture positional coordinates from slides on machine tools and precision instruments; such as are incorporated in semiconductor production equipment, for example. Uses an ABSOLUTE electromagnetic induction system to achieve IP67 environmental resistance. Detects and outputs the absolute position – no reference point setup needed at each power-on. Abnormal calculations do not occur as a result of electrical noise. Very suitable scale for mounting on the X axis of a lathe. The scale main unit has 2 mounting directions for easy installation on machine tools with difficult mounting positions.
View full details
Specification
  • type Coolant Proof
  • range 350mm / 14"
  • display type Without (Via Cable)
  • accuracy ±5 μm
  • measuring units Metric / Imperial
  • measuring method Electromagnetic induction system
  • cable length 3.5 Metres
  • max response speed 50 m/min
  • scale grating pitch 20 μm
  • operating temperature 0 to 45°C
description

Only compatible with KA Counter display units. Designed to capture positional coordinates from slides on machine tools and precision instruments; such as are incorporated in semiconductor production equipment, for example. Uses an ABSOLUTE electromagnetic induction system to achieve IP67 environmental resistance. Detects and outputs the absolute position – no reference point setup needed at each power-on. Abnormal calculations do not occur as a result of electrical noise. Very suitable scale for mounting on the X axis of a lathe. The scale main unit has 2 mounting directions for easy installation on machine tools with difficult mounting positions.
