Mitutoyo

7316S Dial Thickness Gauge, Range 0-0.5", Graduation 0.001"

SKU:Code: 7316S

This item is no longer available or has been discontinued.

Groove depth measurement type. Suitable for measuring narrow grooves. Measuring face of the contact point and anvil are blade-shaped (thickness: 1 mm)
View full details
Specification
  • type Dial Thickness Gauges
  • range 0-0.5"
  • display type Non-Digital
  • graduations 0.001"
  • accuracy ±0.001"
  • bezel dia 2.24"
  • measuring force 1.4 N or less
  • measuring units Imperial
  • stem dia 8mm0.375"
  • throat depth 1.18"
  • remarks Groove depth
  • contact point 0.04" Blade
description

Dial thickness gauges can quickly measure the thickness of thin products. Integrated moulding of the bezel and crystal ensures protection against water and oil penetration via the front face.
