Tesa
01811001 Swisstast Lever Dial Indicator Horizontal Type, Graduation 0.002mm, Range 0.2mm, Scale 0-100-0, Stylus Length 12.53mm, Bezel Diameter 38mm
SKU:Code: Tesa-01811001
Sale
Sold out
Regular price
£144.80
Save: 20%
Sold out
Sale price
£144.80
Regular price
£181.00
Excl. VAT
Well proven over thousands of times. The dial face is parallel to the axis of the measuring inserts
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
Specification
Specification
- type Horizontal Type
- range 0.2mm
- display type Non-Digital
- graduations 0.002mm
- bezel dia 38mm
- measuring force 0.15 N
- measuring units Metric
- scale 0-100-0
- contact point thread M1.4
- repeatability limit 1 µm
description
description
These lever type dial test indicators are especially intended for use on the shop floor or in the inspection room. Ideally suited for comparative measuements on a surface plate for instance
